3D V-Fold Security Fence Panel 4mm Wire Hot-dip Galvanized Powder-Coated
Product Summary:
The 3D security fence panel features one to multiple V-fold ribs formed from a welded wire mesh to significantly boost stiffness and impact resistance without substantial weight increase. Typical panel width is approx. 2500–2520 mm. Mesh options include 50×100, 50×150 and 50×200 mm with standard 4.0 mm wire (3.5–6.0 mm optional). The modular system supports square, rectangular or round posts and multiple foundation methods (in-ground concrete or baseplate anchor), suitable for residential, commercial, industrial and infrastructure perimeter protection.
Manufactured via automatic welding, V-forming, pickling, hot-dip galvanizing (or pre-galvanizing), and powder coating / PVC coating with high-temperature curing. Quality control includes weld strength sampling, coating thickness and adhesion tests, dimensional inspection and visual checks. Packaging is palletized with wooden braces and anti-rust wrapping; staged delivery is available for large projects. Factory inspection certificates and third-party testing can be provided where required. Installation guides and maintenance packages are offered to ensure long-term performance.
Product Information:
3D V-fold security panels are welded wire mesh boards with 2–4 horizontal V-shaped ribs pressed into the panel to increase stiffness and resistance to deformation. Typical panel width ≈ 2.5 m; mesh options include 50×100, 50×150 and 50×200 mm; standard wire dia. 4.0 mm (adjustable).
Characteristics:
V-bend ribs create a built-in reinforcement so panels resist bending, impact and sagging while keeping a low visual profile — “clear-view” aesthetics retained. Surface finishing after galvanizing (powder or PVC) gives corrosion protection for outdoor use.
Application:
Typical uses: residential perimeters, commercial campuses, industrial parks, sports facilities, utility substations and landscape boundaries — anywhere that needs a balance of visibility, durability and basic perimeter deterrence.
Parameter table:
| Panel Width |
2500–2520 mm. |
| Mesh |
50×100 / 50×150 / 50×200 mm (optional). |
| Wire Diameter |
4.0 mm (standard; 3.5–6.0 mm optional). |
| V-Bends |
2–4 ribs per panel . |
| Finish |
Hot-dip galvanized + Powder Coat / PVC optional. |
| Packing |
Pallet + wooden braces + anti-rust wrapping. |
Installation:
Panels mount to standard posts with clamps or bolts; choose in-ground concrete footings or baseplate anchors per site conditions. Inspect fastenings and coatings annually, touch up scratches promptly; coastal projects should consider heavier galvanizing or stainless parts.
